| Part No. | Product Name | D | d. | D1 | L | Tap Size | Compression | Expansion | Adaptor Model | Kgs | Group |
|---|---|---|---|---|---|---|---|---|---|---|---|
| F1VD30X-WFLK1062 | VDI30 TAPPING CHUCK WFLK SIZE 1062 | VDI30 | 19 | 36 | 61.5 | M3 - M12 | 7.5 | 7.5 | WE1 / WES1B | 1.20 | B7000 |
| F1VD30X-WFLK2084 | VDI30 TAPPING CHUCK WFLK SIZE 2084 | VDI30 | 31 | 53 | 84 | M5-M20 | 7.5 | 7.5 | WE2 / WES2B | 1.23 | B7000 |
| F1VD40X-WFLK1062 | VDI40 TAPPING CHUCK WFLK SIZE 1062 | VDI40 | 19 | 36 | 61.5 | M3 - M12 | 7.5 | 7.5 | WE1B / WES1B | 1.52 | B7000 |
| F1VD40X-WFLK2084 | VDI40 TAPPING CHUCK WFLK SIZE 2084 | VDI40 | 31 | 53 | 84 | M5-M20 | 7.5 | 7.5 | WE2B / WES2B | 1.81 | B7000 |
| F1VD50X-WFLK1062 | VDI50 TAPPING CHUCK WFLK SIZE 1062 | VDI50 | 19 | 36 | 61.5 | M3 - M12 | 7.5 | 7.5 | WE1B / WES1B | 2.10 | B7000 |
| F1VD50X-WFLK2080 | VDI50 TAPPING CHUCK WFLK SIZE 2080 | VDI50 | 31 | 53 | 80 | M5-M20 | 7.5 | 7.5 | WE2B / WES2B | 2.32 | B7000 |
